Ford Next-Gen Ranger Light Bar Behind Grille Kit

Key features

• Custom fit for Next-Gen Ford Ranger 2022-on, XL, XLS, XLT, Sport, Wildtrak, Wildtrak X & Platinum
• No bull bar required
• No cutting or drilling required
• Includes choice of Raptor or Nitro Maxx light bars
• Nitro Maxx Light Bars Include the Widr® Optic - This unique reflector delivers market leading output, achieving huge distance with excellent spread
• Solid fitment that doesn’t vibrate on rough roads

In the kit

• Choice of Nitro Maxx or Raptor Light Bars (5700K)
• 1x Wiring harness to suit
• 1x Purpose-built Next-Gen behind-grille black powder-coated bracket kit
• 1x High-beam wiring harness adaptor
• 1x High-beam plug kit for Wildtrak models only
• 1x Mounting hardware kit (nuts, bolts, and brackets)
• Fitting and wiring instructions

Specifications

Wattage

100 Watts

Effective light output

8,865 Lumens

Raw light output

12,320 Lumens

Light source

20 x 5w LED's

Beams

Combo and Widr

Colour temperature

5700K

Waterproof rating

IP68

Voltage

9-36V

Current draw

8A

Dimensions

324 x 92 x 84mm

Net weight

1.9 kg

Housing

6063 T5 Aluminium

Lens

Polycarbonate

Bracket

Sliding Base / Side Mounts

Connector

2 Pin std Deutsch

Operating temperature

-40 to 80 Deg C

Lifespan

50,000 Hours

Warranty

5 Years
